Linking the future Prysmian Group With two internationally renowned commercial brands – Prysmian and Draka – in one united  company, Prysmian Group is the global leader in the cable industry. Based in 50 countries, with  98 plants supported by 22,000 employees, we’re relied on to support the development of the world’s  infrastructure, operating in industries that include utilities, construction, transport, oil and gas, marine,  renewable energy, telecoms and multimedia. Drawing on over 130 years’ expertise and continuously investing in R&D, we apply excellence,  understanding and integrity to everything we do, meeting and exceeding the precise needs  of our customers across all continents and in every sector. Through our experience, commitment to the planet and a passion for innovation, we’re driving the  evolution of our industry. In doing so, we’re connecting today’s opportunities to tomorrow’s possibilities.  In short, we’re linking the future. Introducing xsNet From aerial and underground  installations, through to both  simple and more complex residential  networks, Prysmian’s xsNet family  of products and solutions represents  a new standard   in Fibre To The Home  (FTTH). Answering the critical need for  ease of deployment, flexibility, reliability  and cost-efficiency   – and being backed  by a full suite of valuable support  services – xsNet   is the ideal range  of cabling for today’s changing world. Supported throughout by BendBright XS  fibre technology 2

3 A revolutionary system for fi bre TV cabling VeRTV XS  is an optical Multi Dwelling Unit (MDU) TV cabling solution. The plug and play system  consists of patchcords of various lengths and fl oor boxes for splitting or tap-off . It has been designed to make installation simple as no fi bre optical experience is required for installation, and no fusion or mechanical splicing is needed. Anyone familiar with copper cables, such as electrical engineers, can easily work with this solution. To ensure a balanced installation and a uniform signal to all users, VeRTV XS  allows the installation of three tap-off s plus one splitter ‘in cascade’. This means 32 users can be connected and the insertion loss is lower than 15dB. By means of a1x2 splitter installed at the LNB exit, it is possible to connect 32 users. In this manner, the performance of one single dishis fully optimised.  Technical Parameters Maximum Insertion Loss for 16 outs 15 dB Uniformity Insertion Loss 1 dB Return Loss ≥ 55 dB

Features & Benefi ts Applications Additional Items –  Plug and play –  Miniaturised for use in confi ned  spaces –  Patented mini-adapters and  mini-connectors –  Wide range of tap-off s and splitters –  Splitters integrated into tap-off  –  Typical application: a cascaded 32  user equalised confi guration –  Fibre G657.A2/B2 BeNDBRIGHt XS   (diff erent fi bres available upon request) –  Mini-to-mini patchcords supplied in  standard lengths of 3.5m, 5m, 10m –  Mini-to-FC patchcords supplied in  lengths according to customer’s request –  Cable diameter: 2mm –  Sheath colour of patchcords is white  Sheath material is LS0H UV stable –  Qualifi ed to Telcordia GR326 e IEC  61300 standards –  RoHS compliant materials –  All connectors are supplied with  ceramic ferrules –  Full traceability and test certifi cation  supplied with each assembly –  Tailor-made solutions?  Contact Prysmian Group –   CATV –   FTTx –   Telecommunication –  Data Networks –  Tests & Measurements –  Steel Pulling Wire –  Mini-to-Mini Adapters –  Cleaning Pen –  Inspection Probe 4

5 Main Components Patchcord G657.A2/B2 BendBright XS  (1310/1550nm) Maximum Insertion Loss ≤ 0.3 dB (Typical 0.2 dB) Return Loss ≥ 55 dB Intermateability IEC 874-14 Operating Temperature -40°C to + 85°C Geometrical and Mechanical Parameters Bending Radius 7mm ≤ R ≤ 20mm Max Pulling Force 150 N Connector Diameter 4mm Cable Diameter 2mm Splitters 1x2 1x2 1x2 1x2 1x4 90/10 80/20 70/30 50/50 Maximum Insertion Loss (dB) ≤ 0.8/12.7 ≤ 1.5/8.5 ≤ 2.1/6.4 ≤ 3.9/3.9 ≤ 7.80 Uniformity Insertion Loss (dB) ≤ 0.6/1.2 ≤ 0.6/1.2 ≤ 0.6/1.2 ≤ 1.2 ≤ 1.00 PDL (dB) ≤ 0.3 ≤ 0.3 ≤ 0.2 ≤ 0.20 ≤ 0.25 Return Loss and Directivity (dB) ≥ 50 for the coupler and ≥ 55 for the PLC Operating Temperature (°C) -40°C to +85°C Maximum Input Power (mW) 500 mW Wavelength Range (Nm) 1310±50, 1490±10, 1550±30 for 1x2 1260-1650 for 1x4 Tap-Offs 3/4 2/3 1/2 Max Insertion Loss of 4 Output Legs (dB) ≤ 15.00 ≤ 13.20 ≤ 10.90 Max Insertion Loss of Bypass Leg (dB) ≤ 2.5 ≤ 3.1 ≤ 3.8 Uniformity of Outputs (Client Legs) (dB) ≤ 1.00 Wavelength Range (Nm) 1260 to 1650 Nm Return Loss (dB) ≥ 55 Operating Temperature (°C) -40°C to +85°C PDL (dB)  0.15

Accessories Pulling Wire Stainless steel pulling wire with cable butt connecting system to the mini-connectors.This avoids the need to prepare the cable end beforehand. Also available with dielectric material. Pulling Head for Optical Patchcord The pulling head allows the installation of the pre-connectorised patchcord inside the duct. Mini-to-Mini Adapter Mini-to-mini adapter to connect together two patchcords equipped with mini-connectors. Cleaning Pen Used to clean the adapters and connectors on the splitter and tap-off  boxes. Each pen can be used for 500 cleaning operations. Inspection Probe An inspection kit for the mini-connector which includes a probe, a USB2.0 set, a 3.5" LCD monitor, a special tip and a carrying bag. 6

7 One-stop-shopping with Prysmian’s comprehensive integrated xsNet portfolio Deploying a future-proof FTTx network is all about achieving the highest network reliability and customer satisfaction, whilst making the most of available resources and keeping costs low.  Prysmian’s fully integrated range of connectivity products provides all you need to build or adapt each segment of a low-maintenance FTTx network quickly and cost-eff ectively. Our integrated xsNet range off ers high grade optical fi bre cables, carefully matched and easy-to-handle connectivity components and a choice of ducting solutions for indoor networks, outside plant networks and POP. And there’s more: fl exible design software and engineering advice based on three decades of broadband network design. With minimal eff ort, any network design, regardless of complexity or size, can be put together from scratch, updated or reconfi gured. Prysmian Group’s fi bre optic and  connectivity products –  Combined portfolio brings down the cost of FTTx–   Reach every community with an extensive portfolio of cable, connectivity and deployment technologies  Integrated XSNet concept –   Each  standardised  xsNet solution integrates  seamlessly with the rest of the portfolio  –   Each  xsNet solution contains everything  required to build a specifi c part of the network  –   Operators can make service choices now, but  also accommodate future upgrades and expansion –  Reduces the need for skilled labour–  Excellent logistical support–   Proprietary design software maps, confi gures, optimises  and calculates costs of network concepts in seconds –   Changes and variations are easy to implement whilst  designing and even after installation –   Expert engineering and consultancy services, plus professional support for building a winning business case
