Low Voltage Compact Switch-disconnectors INS/INV40 to 2500 A Catalogue│2013 309E0000.indd 1 29/11/2012 09:12:40
309E0000.indd 2 29/11/2012 09:12:40
I Who else offers such in a wide range ... ... from 40 to 2500 A. A simple product that covers almost all applications. Flexibility to different installation systems thanks to the wide range of accessories. Conformity with International standards. Interpact INS/INV becomes Compact INS/INV Compact INS/INV 1.0 Livre 309EN.indb 1 29/11/2012 09:06:39
II Presentation Who else offers such PB1 1 1402_15.eps PB1 1 1406_20.eps PB1 1 1440_27.eps PB1 1 1442_27.eps PB1 1 1478-27.eps PB1 1 1510_30.eps PB1 1 1516_L41.eps PB1 1 1518_42.eps INS INS40 INS63 INS80 INS100 INS125 INS160 INS250- 100 INS250-160 INS250-200 INS250 INS320 INS400 INS500 INS630 INS630b INS800 INS1000 INS1250 INS1600 INS2000 INS2500 INV INV100 INV160 INV200 INV250 INV320 INV400 INV500 INV630 INV630b INV800 INV1000 INV1250 INV1600 INV2000 INV2500 Ith at 60 °C 40 63 80 100 125 160 100 160 200 250 320 400 500 630 630 800 1000 1250 1600 (1) 2000 2500 Ui CA 50/60 Hz/CC (V) 690 690 690 750 750 750 800 800 800 800 800 800 800 800 800 1000 1000 1000 1000 1000 1000 Uimp (kV) 8 8 8 8 8 8 8 8 8 8 8 8 8 8 12 12 12 12 12 12 12 Ue AC22A 380/415 V 40 63 80 100 125 160 100 160 200 250 320 400 500 630 630 800 1000 1250 1450/1600 (2) 2000 (3) 2500 (3) Ue AC22A 660/690 V - - - 100 125 160 100 160 200 250 320 400 500 630 630 800 1000 1250 1250/1600 (2) 2000 (3) 2500 (3) Ue AC23A 380/415 V 40 63 72 100 125 160 100 160 200 250 320 400 500 630 630 800 1000 1250 1250 - - Ue AC23A 500/525 V 32 40 40 100 125 160 100 160 200 250 320 400 500 630 630 800 1000 1250 1250 - - Ue AC23A 660/690 V - - - 63 80 100 100 160 200 250 320 400 500 630 630 800 1000 1250 1250 - - (1) 1600 A at 45 °C and 1450 A at 60 °C. (2) Ue AC22A / AC22B. (3) Ue AC22B. Identical performance up to 500/690 V Availalibity everywhere INS/INV switch-disconnectors ... for high industrial performance ... for maximum operational voltage Source changeover systems from 100 to 630 A, with identical performance 309E0100.indd 2 04/12/2012 10:40:52
III high performances and safety ? PB1 1 1402_15.eps PB1 1 1406_20.eps PB1 1 1440_27.eps PB1 1 1442_27.eps PB1 1 1478-27.eps PB1 1 1510_30.eps PB1 1 1516_L41.eps PB1 1 1518_42.eps INS INS40 INS63 INS80 INS100 INS125 INS160 INS250- 100 INS250-160 INS250-200 INS250 INS320 INS400 INS500 INS630 INS630b INS800 INS1000 INS1250 INS1600 INS2000 INS2500 INV INV100 INV160 INV200 INV250 INV320 INV400 INV500 INV630 INV630b INV800 INV1000 INV1250 INV1600 INV2000 INV2500 Ith at 60 °C 40 63 80 100 125 160 100 160 200 250 320 400 500 630 630 800 1000 1250 1600 (1) 2000 2500 Ui CA 50/60 Hz/CC (V) 690 690 690 750 750 750 800 800 800 800 800 800 800 800 800 1000 1000 1000 1000 1000 1000 Uimp (kV) 8 8 8 8 8 8 8 8 8 8 8 8 8 8 12 12 12 12 12 12 12 Ue AC22A 380/415 V 40 63 80 100 125 160 100 160 200 250 320 400 500 630 630 800 1000 1250 1450/1600 (2) 2000 (3) 2500 (3) Ue AC22A 660/690 V - - - 100 125 160 100 160 200 250 320 400 500 630 630 800 1000 1250 1250/1600 (2) 2000 (3) 2500 (3) Ue AC23A 380/415 V 40 63 72 100 125 160 100 160 200 250 320 400 500 630 630 800 1000 1250 1250 - - Ue AC23A 500/525 V 32 40 40 100 125 160 100 160 200 250 320 400 500 630 630 800 1000 1250 1250 - - Ue AC23A 660/690 V - - - 63 80 100 100 160 200 250 320 400 500 630 630 800 1000 1250 1250 - - (1) 1600 A at 45 °C and 1450 A at 60 °C. (2) Ue AC22A / AC22B. (3) Ue AC22B. Identical performance up to 500/690 V Also exists in versions Standard with visible break. Emergency-off switch-disconnector with positive contact indication. Emergency-off switch-disconnector with visible break. Standards and certifications DB404181.eps The Compact INS/INV range complies with international standards, as officially certified by an independent organisation. IEC 60 947-1, IEC 60 947-3 EN 60 947-1, EN 60 947-3 DB107389.eps Conformity with UL and CSA standards Special versions of Compact INS/INV switch-disconnectors are available that comply with UL and CSA standards for moulded case switches. UL489 and CSA C22.2 No. 5-02 b The entire range has been fully certified IEC 60947-1, IEC 60947-3 and EN 60947-1, EN 60947-3. Certification was carried out within the framework of the LOVAG agreement by independent certification organisations. b Marine certification is underway. b Certain ratings are UL listed (UL 489 listed for the switch part) for markets requiring such certification. 309E0100.indd 3 04/12/2012 10:40:54
IV Presentation PB1 1 1572_45.eps PB1 1 1556.eps DB404205.eps PD395007_L70_SE.eps PB1 1 1807_104.eps Local isolation enclosures b Current ratings: up to 63 A for commercial and 630 A for industrial applications v Schneider Electric switch-disconnectors v NG125NA, Compact INS40 to 160 and I modular switches v Compact INS/INV v Schneider Electric switch-disconnectors b Vario 12 to 175 A. Control panels b Current ratings: up to 63/80 A b Schneider Electric switch-disconnectors: v Compact INS b Schneider Electric switch-disconnectors v Vario. Sub-distribution boards b Current ratings: up to 160 A b Schneider Electric switch-disconnectors: v Compact INS/INV v NG125. Industrial switchboards and automatic control panels b Current ratings: up to 400 A b Schneider Electric switch-disconnectors: v Compact INS/INV. DB106821.eps Local isolation Industrial or commercial Main power distribution boards for commercial and industrial applications b Current ratings: v 400 to 1000 A for commercial applications v 400 to 1600 A for industrial applications b Schneider Electric switch-disconnectors: v Compact INS/INV v Masterpact NA/HA/HA10/HF. Final distribution Sub-distribution Power distribution Who else covers Livre 309EN.indb 4 29/11/2012 09:06:44
V PB1 1 1572_45.eps PB1 1 1556.eps DB404205.eps PD395007_L70_SE.eps PB1 1 1807_104.eps Local isolation enclosures b Current ratings: up to 63 A for commercial and 630 A for industrial applications v Schneider Electric switch-disconnectors v NG125NA, Compact INS40 to 160 and I modular switches v Compact INS/INV v Schneider Electric switch-disconnectors b Vario 12 to 175 A. Control panels b Current ratings: up to 63/80 A b Schneider Electric switch-disconnectors: v Compact INS b Schneider Electric switch-disconnectors v Vario. Sub-distribution boards b Current ratings: up to 160 A b Schneider Electric switch-disconnectors: v Compact INS/INV v NG125. Industrial switchboards and automatic control panels b Current ratings: up to 400 A b Schneider Electric switch-disconnectors: v Compact INS/INV. DB106821.eps Local isolation Industrial or commercial Main power distribution boards for commercial and industrial applications b Current ratings: v 400 to 1000 A for commercial applications v 400 to 1600 A for industrial applications b Schneider Electric switch-disconnectors: v Compact INS/INV v Masterpact NA/HA/HA10/HF. Final distribution Sub-distribution Power distribution so many applications? Livre 309EN.indb 5 29/11/2012 09:06:44
VI Presentation LV devices Acti 9 NG125 Easypact Compact NS Masterpact NT Micrologic Compact INS Compact INV Fupact INF NG160 Compact NSX Compact NSX DC Masterpact NW Masterpact NW DC Compact INS/INV Source-changeover FupactISFT FupactISFL A complete offering Finaldistributionenclosureforcommercialapplications Main power distribution board for commercial applications Main power distribution board for industrial applications DB414486.eps 309E0100 Version : 1.1 06/12/2012 309E0100.indd 6 06/12/2012 09:22:04
VII for all your needs Power distribution incomers and coupling devices PB106363A35_L49.eps PB1 11518_42.eps DB404184.eps Masterpact NW25HA. Compact INS2000. Compact NS1600NA. Final distribution outgoers and local isolation and control devices PB104825.eps PB101050b-17.eps PB1 11439_l22.eps 056908N_L28_SE .eps PB1 11402_15.eps 9262_SE_20.eps PB107917- 17.eps Compact NSX250NA. Compact NS250NA. Compact INV250. NG125. Compact INS80. Vario. Acti 9. Sub-distribution incomers PB104826.eps PB104824.eps PB1 11489_43.eps PB1 11484_L20.eps 056908N_L28_SE .eps Compact NSX400NA. Compact NS400NA. Compact INS630 complete source-changeover assembly. Compact INV400. NG125. 309E0100.indd 7 04/12/2012 11:20:11
Ecodial software is dedicated to LV electrical installation calculation in accordance with the IEC60364 international standard or national standards. This 4 th generation, "Ecodial Advance Calculation 4", offers a new ergonomic and new features: p operating mode that allows easy calculation in case of installation with different type of sources (parallel transformers, back-up generators…) p discrimination analysis associating curves checking and discrimination tables p direct access to protection settings including residual current protections p easy selection of alternate solutions or manual selection of a product. Ecodial TOOLS Livre 309EN.indb 2 29/11/2012 09:06:53
1 Compact INS/INV Presentation 2 Functions and characteristics A -1 Installation recommendations B -1 Dimensions and connection C -1 Complementary technical information D -1 Catalogue numbers E -1 Contents Livre 309EN.indb 1 29/11/2012 09:06:53
Presentation 1.1 Overview 2 Compact INS Switch-disconnectors with positive contact indication Emergency-off switch-disconnectors with positive contact indication Compact INV Switch-disconnectors with visible break Emergency-off switch-disconnectors with visible break The complete range 40 A 63 A 80 A 100 A 125 A 160 A 200 A 250 A 320 A 400 A 500 A 630 A 630b A 800 A 1000 A 1250 A 1600 A 2000 A 2500 A Modular profile INS40 INS63 INS80PV INS100 INS125 INS160 INS250-100 INS250-160 INS250-200 INS250 INS320 INS400 INS500 INS630 INS630b INS800 INS1000 INS1250 INS1600 INS2000 INS2500 INSE 40-80 INSJ400 Mounting on backplate INV100 INV160 INV200 INV250 INV320 INV400 INV500 INV630 INV630b INV800 INV1000 INV1250 INV1600 INV2000 INV2500 309E1100.indd 2 17/12/2012 08:56:37
3 309E1100 Version : 1.1 17/12/2012 Compact INS Switch-disconnectors with positive contact indication Emergency-off switch-disconnectors with positive contact indication Compact INV Switch-disconnectors with visible break Emergency-off switch-disconnectors with visible break The complete range 40 A 63 A 80 A 100 A 125 A 160 A 200 A 250 A 320 A 400 A 500 A 630 A 630b A 800 A 1000 A 1250 A 1600 A 2000 A 2500 A Modular profile INS40 INS63 INS80PV INS100 INS125 INS160 INS250-100 INS250-160 INS250-200 INS250 INS320 INS400 INS500 INS630 INS630b INS800 INS1000 INS1250 INS1600 INS2000 INS2500 INSE 40-80 INSJ400 Mounting on backplate INV100 INV160 INV200 INV250 INV320 INV400 INV500 INV630 INV630b INV800 INV1000 INV1250 INV1600 INV2000 INV2500
4 Presentation 1.1 INS for positive contact indication and INV for visible break PB1 11482_35.eps A mechanical system ensures that the position of the handle always reflects the position of the main contacts. With positive contact indication, Schneider Electric guarantees optimum safety for all users of the Compact INS/INV range. PB1 11484_37.eps The physical separation of the main contacts is directly visible through a transparent cover. With this visible break function in addition to positive contact indication, the Compact INV range offers double safety. Rotary, front and lateral handles... a very wide choice. PB1 11442_30_R.eps PB1 11565_26_R.eps PB1 11562_30_R.eps PB1 11561_27_R.eps PB1 11402_25_R.eps PB1 11564_30_R.eps Specially design handles for easy operation PB1 11510_39.eps The interruption of current flowing in high-power circuits is associated with high mechanical forces within small volumes. To facilitate the operation of the Compact INS/INV range of switch-disconnectors, Schneider Electric has paid particular attention to the design of the handles. As a result, the Compact INS/INV range offers both high performance and easy operation. Designed to work 309E1400.indd 4 04/12/2012 13:31:42
5 the way you work One-piece spreader PB103721_R.eps INS and INV devices may be equipped with a spreader corresponding to the pitch of the terminals of the next highest frame size, just like Compact devices. This one-piece spreader offers improved accessibility and ensures a uniform electrical installation. It may be fitted with all the connection and isolation accessories of the Compact device with the next highest frame size. PB 11 1568 _L18 0_R. eps 309E1400.indd 5 04/12/2012 13:31:46
6 Presentation b Easy installation b Built-in safety b Automatic interlocking b Simple operating mechanism Manual source- changeover systems: Livre 309EN.indb 6 29/11/2012 09:07:05
7 solutions for continuous performance The complete source-changeover assembly makes it possible to transfer between a normal source (N) and a replacement source (R) using a single operating handle Livre 309EN.indb 7 29/11/2012 09:07:05
